YZ2400 Disk(full Range)underground Electronic Marker

Availability:
Quantity:
  •  PRODUCT DESCRIPTION

YZ2400 Underground Electronic Marker has two models (ID or No ID). It consists of a sealed shell containing a passive antenna - a low-frequency resonance circuit tuned to a certain frequency. The ID version integrates an ID chip.
Depending on the resonant frequency and the color, the YZ2400 are used to mark a wide range of underground facilities, such as telecommunication lines, power supply networks, cable television networks, water supply pipelines, wastewater networks, oil and gas pipelines, and so on.


  • APPLICATIONS

YZ2400 can be installed at a certain interval, or at the turning of changing trend and at some event points, such as connection points, valves, well covers, T-shaped branches, etc. According to the project importance and project budget, the installing density can vary from several meters to tens of meters, usually 10-20 meters.

·   Pipeline path

·   Nonmetallic pipe

·   Various valves

·   Metering meter

·   Various crossing points

·   Tee

·   Depth change

·   Pressure reducing device

·   Catholic protection

·   Pressure control point

·   Embedded reserved port

·   Various elbows

·   Pipe diameter change

·   Water well

·   Cover

·   Maintenance point

·   ……


  • FEATURES

1.      Physical characteristics

·   Shell: HDPE

·   weight:385g±10%

·   Case diameter - 15.7in (400mm)

·   Case height - 1.26in (3.2cm)

·   Rockwell hardness: R-116

·   Softening point: 105 ℃

2.      Environmental characteristics

·   Working temperature: - 20 ℃ - 50 ℃

·   Storage temperature: - 20 ℃ - 70 ℃

·   Drop test: it can withstand the drop from 10 feet (about 3 meters) to the concrete floor

·   Waterproof and dust-proof: IP68

3.      Electrical characteristics

·   Maximum detectable depth : 2.6~3.0m (Slightly different in different frequencies)

·   Maximum ID reading distance : 2.3~2.5m (Slightly different in different frequencies)

·   Minimum distance from the metal facility to marker : 15cm

·   Global Unique ID code(ID Version): 10 digits

·   Compatible locator:

     No ID version: Any Locator with analog mode

     ID version:  ED-8000 locator

·   Frequency (customizable):

     Power1 169.8KHz(CN)

     Power2 134KHz(EU)

     Water 145.7 KHz

     Sanitary 121.6 KHz

     Telecom 101.4 KHz

     Gas 83 KHz

     General 66.35 KHz

  Installing the Marker

· Place the marker on nonmetal cable

· Place a minimum of 5.9 inches (15 cm) of fill dirt over the cable with metal (including shielded cable, Coaxial cable etc.).
